Ford F-150 Lease & Finance Specials In Mandan ND

An Astonishingly Sleek and Captivating Pickup

While the F-150 is known for its "work-first" lineage, this truck also knows a ton about cutting a slick profile on the streets of Mandan. Specifically, offering up a selection of seven interior color styles, 14 exterior paint options, and even Chrome and Sport packages that encourage you to undoubtedly tailor-make the F-150 that ends up in your front driveway.

Stay Hooked up with Futuristic LCD Screen Technology

Maximize the inside aesthetics with top-tier technology — XL 101A and XLT versions come standard with a 4.2-inch (in.) color LCD display, while the Lariat, Ranch, King Ranch, Platinum, Limited, and Raptor editions lay claim to an eight-in. LCD screen. What is more, this eight-in. color screen offers up the convenience of having access to AppLink, SYNC 3, 911 Assist, and plenty of other exceptional tech enhancements.

Selecting the Right F-150 Trim Package for You

Ford F-150 XL

Completely tackle the most difficult activities with F-150 XL’s standard 3.3-liter (L) Ti-VCT V6 motor, fully boxed frame, Trailer Sway Control, and military-grade, hardened aluminum alloy body. In addition, shift to four-wheel drive by just twisting the electronic-shift-on-the-fly (ESOF) control, and hitch up this sleeker, tougher pickup to a trailer receiver using the Rear-View Camera with Dynamic Hitch Assist.

Ford F-150 Raptor

Push your off-road expertise to the limits and surge ahead quicker during particular power band stages through F-150 Raptor’s twin-turbo 3.5-L EcoBoost engine that unleashes 450-horsepower (hp), a 10-speed automatic transmission, and 3.0-in. FOX Racing Shox. Everyone will certainly notice the huge front skid plate and aggressive-looking grille with large FORD block lettering and built-in marker lights, as well.

2019 white F-150 Platinum for sale at Eide Ford Mandan in Mandan.

Ford F-150 Platinum

Have fun with extra amounts of convenience to owning an industry-defining truck with 20-in. polished aluminum rims and category-leading payload in the temperature-controlled, multi-contour leather front bucket seating of the F-150 Platinum. Running on a 395-hp 5.0-L Ti-VCT V8 motor, the Ford F-150 Platinum likewise offers up plenty of handy, state-of-the-art tools, like SYNC 3, SYNC Connect, and an eight-in. LCD screen that you can tailor-make.

Ford F-150 Highlights

Taking Power to Another Level

To start, the F-150 is a pickup built on a base of endurance and hardy sturdiness. At its foundation, a dent-resilient, military-grade aluminum alloy physique helps keep your F-150 light, nimble, and strong, all at once. As for the skeleton, hardened steel ensures strength and rigidity are never in question. Finally, you get to enjoy quite a few performance choices in terms of engine packages, such as:

*3.3-L V6*	*2.7-L EcoBoost V6*	*3.5-L EcoBoost V6*	*3.0-L Power Stroke Turbo Diesel*	*5.0-L TI-VCT V8*	*Raptor DOHC 24-valve, 3.5-L EcoBoost*
290 hp	325 hp	375 hp	250 hp	395 hp	450 hp
265 pound-feet (lb-ft.) of torque	400 lb-ft. of torque	470 lb-ft. of torque	440 lb-ft. of torque	400 lb-ft. of torque	510 lb-ft. of torque

Space for the Whole Gang (and Your Equipment, Too)

The new F-150 gives you an ample amount of room to cart other riders and whatever else you might want for a weekend of hard work or leisure in Mandan ND. With the 5.5-in. Styleside Box, you get 52.8 cubic-feet (cu.-ft.) of volume. The 6.5-in. Styleside Box gives you 62.3 cu.-ft. of space. Finally, the eight-in. Styleside Box tops the conversation with 77.4 cu.-ft. of cargo space. Get more from your pickup bed with the available BoxLink package (an add-on that includes four locking cleats), in addition to the portable bed extender. If you want to protect your F-150 box from corrosion, scratches, and dings, a spray-in bedliner is worth considering.

The F-150 Owns Towing

Pulling ability with the F-150 is at the top of its class. Depending on the motor, this truck can haul from between 8,500 pounds (lbs.) to 12,200 lbs. With intelligent tools like a rear view lens (which comes with Dynamic Hitch Assist) and two optional towing packages (Trailer Tow and Maximum Trailer Tow) to make use of, connecting with your trailer is way less stressful. The Reverse Sensing System guarantees you are notified should something cross your direction while you back up, and the Trailer Sway Control package helps with speed and stopping power to guarantee you are able to continue hauling without incident.

Never Easing up on Safety

Tech and safety features found in the latest Ford F-150s at Eide Ford Mandan in Mandan.

The F-150s for sale or lease at Eide Ford Mandan also make use of a plethora of outstanding safety systems. To start, F-150's AdvanceTrac with Roll Stability and Curve Control acts to limit wheel instability and will help you take tight turns and unanticipated bends at acceptable speeds. The Safety Canopy feature, which provides added side-curtain airbags to the standard front seat and side-front area airbags, also incorporates a rollover sensor. Having access to the MyKey system lets you set different keys with various driving limitations to encourage safe driving habits for everyone who is a part of your household.

For buyers or leasers in Mandan looking for a rough and dependable pickup that rises above the rest, Eide Ford Mandan would suggest to you Ford’s most recent iteration of the F-150. In undertaking this, you will soon see why Ford's F-150 consistently reigns supreme as the highest-selling pickup in America.

Now that Eide Ford Mandan has offered up all of this, we honestly only have a single question to send you way: Is it not time you visit Eide Ford Mandan and find out for yourself why owning or leasing a F-150 for you and your family is a choice that you will never regret?

Trim Level Market Research

Ford F-150 - King Ranch 2WD SuperCrew 5.5' Box - Starting From: $52,390

Pricing

Starting From $52,390

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3375

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2692

Curb Weight - Rear 1916

Gross Vehicle Weight Rating Cap 6800

Gross Combined Wt Rating 12100

Dead Weight Hitch - Max Trailer Wt. 7000

Dead Weight Hitch - Max Tongue Wt. 700

Wt Distributing Hitch - Max Trailer Wt. 7000

Wt Distributing Hitch - Max Tongue Wt. 700

Maximum Trailering Capacity 7000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3375

Spring Capacity - Rear 3800

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.15

Axle Ratio (:1) - Rear 3.15

Front Tire Order Code T82

Rear Tire Order Code T82

Spare Tire Order Code T22

Front Tire Size P265/60SR18

Rear Tire Size P265/60SR18

Spare Tire Size Full-Size

Front Tire Capacity 3650

Rear Tire Capacity 4056

Front Wheel Size 20 X 8.5

Rear Wheel Size 20 X 8.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 47.8

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 19 (Est)

EPA Fuel Economy Est - City 17 (Est)

EPA Fuel Economy Est - Hwy 25 (Est)

Engine Order Code 995

Engine Type Regular Unleaded V-8

Displacement 5.0 L/302

Fuel System Diesel Injection

SAE Net Horsepower @ RPM 395 @ 5750

SAE Net Torque @ RPM 400 @ 4500

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model None

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.4

Second Leg Room 43.6

Second Shoulder Room 65.9

Second Hip Room 64.7

Wheelbase 145

Length, Overall w/o rear bumper 231.9

Width, Max w/o mirrors 79.9

Height, Overall 75.6

Overhang, Front 37.8

Ground to Top of Load Floor 34

Ground Clearance, Front 8.7

Ground Clearance, Rear 8.7

Cargo Box Length @ Floor 66

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 52.8

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - King Ranch 2WD SuperCrew 6.5' Box - Starting From: $52,690

Pricing

Starting From $52,690

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3450

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2749

Curb Weight - Rear 1892

Gross Vehicle Weight Rating Cap 6950

Gross Combined Wt Rating 12100

Dead Weight Hitch - Max Trailer Wt. 7000

Dead Weight Hitch - Max Tongue Wt. 700

Wt Distributing Hitch - Max Trailer Wt. 7000

Wt Distributing Hitch - Max Tongue Wt. 700

Maximum Trailering Capacity 7000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3450

Spring Capacity - Rear 3800

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.15

Axle Ratio (:1) - Rear 3.15

Front Tire Order Code T82

Rear Tire Order Code T82

Spare Tire Order Code T22

Front Tire Size P265/60SR18

Rear Tire Size P265/60SR18

Spare Tire Size Full-Size

Front Tire Capacity 3650

Rear Tire Capacity 4056

Front Wheel Size 20 X 8.5

Rear Wheel Size 20 X 8.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 51.1

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 19 (Est)

EPA Fuel Economy Est - City 17 (Est)

EPA Fuel Economy Est - Hwy 25 (Est)

Engine Order Code 995

Engine Type Regular Unleaded V-8

Displacement 5.0 L/302

Fuel System Diesel Injection

SAE Net Horsepower @ RPM 395 @ 5750

SAE Net Torque @ RPM 400 @ 4500

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model None

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.4

Second Leg Room 43.6

Second Shoulder Room 65.9

Second Hip Room 64.7

Wheelbase 157

Length, Overall w/o rear bumper 243.7

Width, Max w/o mirrors 79.9

Height, Overall 75.7

Overhang, Front 37.8

Ground to Top of Load Floor 35.7

Ground Clearance, Front 8.4

Ground Clearance, Rear 8.4

Cargo Box Length @ Floor 78

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 62.3

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - King Ranch 4WD SuperCrew 5.5' Box - Starting From: $55,815

Pricing

Starting From $55,815

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3600

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2918

Curb Weight - Rear 1950

Gross Vehicle Weight Rating Cap 7000

Gross Combined Wt Rating 12400

Dead Weight Hitch - Max Trailer Wt. 7000

Dead Weight Hitch - Max Tongue Wt. 700

Wt Distributing Hitch - Max Trailer Wt. 7000

Wt Distributing Hitch - Max Tongue Wt. 700

Maximum Trailering Capacity 7000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3600

Spring Capacity - Rear 3800

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.31

Axle Ratio (:1) - Rear 3.31

Front Tire Order Code T88

Rear Tire Order Code T88

Spare Tire Order Code T24

Front Tire Size P275/55SR20

Rear Tire Size P275/55SR20

Spare Tire Size Full-Size

Front Tire Capacity 3650

Rear Tire Capacity 4056

Front Wheel Size 20 X 8.5

Rear Wheel Size 20 X 8.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 47.8

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 18 (Est)

EPA Fuel Economy Est - City 16 (Est)

EPA Fuel Economy Est - Hwy 22 (Est)

Engine Order Code 995

Engine Type Regular Unleaded V-8

Displacement 5.0 L/302

Fuel System Diesel Injection

SAE Net Horsepower @ RPM 395 @ 5750

SAE Net Torque @ RPM 400 @ 4500

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model Electronic

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.4

Second Leg Room 43.6

Second Shoulder Room 65.9

Second Hip Room 64.7

Wheelbase 145

Length, Overall w/o rear bumper 231.9

Width, Max w/o mirrors 79.9

Height, Overall 77.2

Overhang, Front 37.8

Ground to Top of Load Floor 34.6

Ground Clearance, Front 9.3

Ground Clearance, Rear 9.3

Cargo Box Length @ Floor 66

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 52.8

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - King Ranch 4WD SuperCrew 6.5' Box - Starting From: $56,115

Pricing

Starting From $56,115

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3750

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2984

Curb Weight - Rear 1929

Gross Vehicle Weight Rating Cap 7100

Gross Combined Wt Rating 12400

Dead Weight Hitch - Max Trailer Wt. 7000

Dead Weight Hitch - Max Tongue Wt. 700

Wt Distributing Hitch - Max Trailer Wt. 7000

Wt Distributing Hitch - Max Tongue Wt. 700

Maximum Trailering Capacity 7000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3750

Spring Capacity - Rear 3800

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.31

Axle Ratio (:1) - Rear 3.31

Front Tire Order Code T88

Rear Tire Order Code T88

Spare Tire Order Code T24

Front Tire Size P275/55SR20

Rear Tire Size P275/55SR20

Spare Tire Size Full-Size

Front Tire Capacity 3650

Rear Tire Capacity 4056

Front Wheel Size 20 X 8.5

Rear Wheel Size 20 X 8.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 51.1

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 18 (Est)

EPA Fuel Economy Est - City 16 (Est)

EPA Fuel Economy Est - Hwy 22 (Est)

Engine Order Code 995

Engine Type Regular Unleaded V-8

Displacement 5.0 L/302

Fuel System Diesel Injection

SAE Net Horsepower @ RPM 395 @ 5750

SAE Net Torque @ RPM 400 @ 4500

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model Electronic

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.4

Second Leg Room 43.6

Second Shoulder Room 65.9

Second Hip Room 64.7

Wheelbase 157

Length, Overall w/o rear bumper 243.7

Width, Max w/o mirrors 79.9

Height, Overall 77.3

Overhang, Front 37.8

Ground to Top of Load Floor 36.1

Ground Clearance, Front 9.3

Ground Clearance, Rear 9.3

Cargo Box Length @ Floor 78

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 62.3

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - LARIAT 2WD SuperCab 6.5' Box - Starting From: $42,200

Pricing

Starting From $42,200

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3375

Gross Axle Wt Rating - Rear 3350

Curb Weight - Front 2651

Curb Weight - Rear 1855

Gross Vehicle Weight Rating Cap 6400

Gross Combined Wt Rating 10000

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 5000

Wt Distributing Hitch - Max Tongue Wt. 500

Maximum Trailering Capacity 5000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3375

Spring Capacity - Rear 3350

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.73

Axle Ratio (:1) - Rear 3.73

Front Tire Order Code T82

Rear Tire Order Code T82

Spare Tire Order Code T22

Front Tire Size P265/60SR18

Rear Tire Size P265/60SR18

Spare Tire Size Full-Size

Front Tire Capacity 3650

Rear Tire Capacity 4056

Front Wheel Size 20 X 8.5

Rear Wheel Size 20 X 8.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 47.1

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 21 (Est)

EPA Fuel Economy Est - City 18 (Est)

EPA Fuel Economy Est - Hwy 26 (Est)

Engine Order Code 99P

Engine Type Twin Turbo Regular Unleaded V-6

Displacement 2.7 L/164

Fuel System Diesel Injection

SAE Net Horsepower @ RPM 325 @ 5000

SAE Net Torque @ RPM 400 @ 2750

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model None

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.3

Second Leg Room 33.5

Second Shoulder Room 65.8

Second Hip Room 64.7

Wheelbase 145

Length, Overall w/o rear bumper 231.9

Width, Max w/o mirrors 79.9

Height, Overall 75.5

Overhang, Front 37.8

Ground to Top of Load Floor 34.1

Ground Clearance, Front 8.7

Ground Clearance, Rear 8.7

Cargo Box Length @ Floor 78

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 62.3

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - LARIAT 2WD SuperCab 8' Box - Starting From: $42,500

Pricing

Starting From $42,500

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3525

Gross Axle Wt Rating - Rear 3350

Curb Weight - Front 2743

Curb Weight - Rear 1901

Gross Vehicle Weight Rating Cap 7000

Gross Combined Wt Rating 10100

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 5000

Wt Distributing Hitch - Max Tongue Wt. 500

Maximum Trailering Capacity 5000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3525

Spring Capacity - Rear 3350

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.73

Axle Ratio (:1) - Rear 3.73

Front Tire Order Code T82

Rear Tire Order Code T82

Spare Tire Order Code T22

Front Tire Size P265/60SR18

Rear Tire Size P265/60SR18

Spare Tire Size Full-Size

Front Tire Capacity 3650

Rear Tire Capacity 4056

Front Wheel Size 20 X 8.5

Rear Wheel Size 20 X 8.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 53

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 21 (Est)

EPA Fuel Economy Est - City 18 (Est)

EPA Fuel Economy Est - Hwy 26 (Est)

Engine Order Code 99P

Engine Type Twin Turbo Regular Unleaded V-6

Displacement 2.7 L/164

Fuel System Port/Direct Injection

SAE Net Horsepower @ RPM 325 @ 5000

SAE Net Torque @ RPM 400 @ 2750

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model None

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 2.7

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.3

Second Leg Room 33.5

Second Shoulder Room 65.8

Second Hip Room 64.7

Wheelbase 163

Length, Overall w/o rear bumper 250.5

Width, Max w/o mirrors 79.9

Height, Overall 75.5

Overhang, Front 37.8

Ground to Top of Load Floor 35.9

Ground Clearance, Front 8.6

Ground Clearance, Rear 8.6

Cargo Box Length @ Floor 96

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 77.4

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - LARIAT 2WD SuperCrew 5.5' Box - Starting From: $44,560

Pricing

Starting From $44,560

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3375

Gross Axle Wt Rating - Rear 3350

Curb Weight - Front 2672

Curb Weight - Rear 1931

Gross Vehicle Weight Rating Cap 6360

Gross Combined Wt Rating 10100

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 5000

Wt Distributing Hitch - Max Tongue Wt. 500

Maximum Trailering Capacity 5000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3375

Spring Capacity - Rear 3350

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.73

Axle Ratio (:1) - Rear 3.73

Front Tire Order Code T82

Rear Tire Order Code T82

Spare Tire Order Code T22

Front Tire Size P265/60SR18

Rear Tire Size P265/60SR18

Spare Tire Size Full-Size

Front Tire Capacity 3650

Rear Tire Capacity 4056

Front Wheel Size 18 X 7.5

Rear Wheel Size 18 X 7.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 47.8

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 21 (Est)

EPA Fuel Economy Est - City 18 (Est)

EPA Fuel Economy Est - Hwy 26 (Est)

Engine Order Code 99P

Engine Type Twin Turbo Regular Unleaded V-6

Displacement 2.7 L/164

Fuel System Diesel Injection

SAE Net Horsepower @ RPM 325 @ 5000

SAE Net Torque @ RPM 400 @ 2750

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model None

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.4

Second Leg Room 43.6

Second Shoulder Room 65.9

Second Hip Room 64.7

Wheelbase 145

Length, Overall w/o rear bumper 231.9

Width, Max w/o mirrors 79.9

Height, Overall 75.6

Overhang, Front 37.8

Ground to Top of Load Floor 34

Ground Clearance, Front 8.7

Ground Clearance, Rear 8.7

Cargo Box Length @ Floor 66

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 52.8

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - LARIAT 2WD SuperCrew 6.5' Box - Starting From: $44,860

Pricing

Starting From $44,860

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3450

Gross Axle Wt Rating - Rear 3350

Curb Weight - Front 2746

Curb Weight - Rear 1882

Gross Vehicle Weight Rating Cap 6500

Gross Combined Wt Rating 10100

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 5000

Wt Distributing Hitch - Max Tongue Wt. 500

Maximum Trailering Capacity 5000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3450

Spring Capacity - Rear 3350

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.73

Axle Ratio (:1) - Rear 3.73

Front Tire Order Code T82

Rear Tire Order Code T82

Spare Tire Order Code T22

Front Tire Size P265/60SR18

Rear Tire Size P265/60SR18

Spare Tire Size Full-Size

Front Tire Capacity 3650

Rear Tire Capacity 4056

Front Wheel Size 18 X 7.5

Rear Wheel Size 18 X 7.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 51.1

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 21 (Est)

EPA Fuel Economy Est - City 18 (Est)

EPA Fuel Economy Est - Hwy 26 (Est)

Engine Order Code 99P

Engine Type Twin Turbo Regular Unleaded V-6

Displacement 2.7 L/164

Fuel System Diesel Injection

SAE Net Horsepower @ RPM 325 @ 5000

SAE Net Torque @ RPM 400 @ 2750

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model None

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.4

Second Leg Room 43.6

Second Shoulder Room 65.9

Second Hip Room 64.7

Wheelbase 157

Length, Overall w/o rear bumper 243.7

Width, Max w/o mirrors 79.9

Height, Overall 75.7

Overhang, Front 37.8

Ground to Top of Load Floor 35.7

Ground Clearance, Front 8.4

Ground Clearance, Rear 8.4

Cargo Box Length @ Floor 78

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 62.3

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - LARIAT 4WD SuperCab 6.5' Box - Starting From: $45,625

Pricing

Starting From $45,625

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3600

Gross Axle Wt Rating - Rear 3350

Curb Weight - Front 2903

Curb Weight - Rear 1903

Gross Vehicle Weight Rating Cap 7050

Gross Combined Wt Rating 10200

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 5000

Wt Distributing Hitch - Max Tongue Wt. 500

Maximum Trailering Capacity 5000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3600

Spring Capacity - Rear 3350

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.73

Axle Ratio (:1) - Rear 3.73

Front Tire Order Code T88

Rear Tire Order Code T88

Spare Tire Order Code T24

Front Tire Size P275/65SR18

Rear Tire Size P275/65SR18

Spare Tire Size Full-Size

Front Tire Capacity 3650

Rear Tire Capacity 4056

Front Wheel Size 20 X 8.5

Rear Wheel Size 20 X 8.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 47.1

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 21 (Est)

EPA Fuel Economy Est - City 19 (Est)

EPA Fuel Economy Est - Hwy 24 (Est)

Engine Order Code 99P

Engine Type Twin Turbo Regular Unleaded V-6

Displacement 2.7 L/164

Fuel System Diesel Injection

SAE Net Horsepower @ RPM 325 @ 5000

SAE Net Torque @ RPM 400 @ 2750

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model Electronic

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.3

Second Leg Room 33.5

Second Shoulder Room 65.8

Second Hip Room 64.7

Wheelbase 145

Length, Overall w/o rear bumper 231.9

Width, Max w/o mirrors 79.9

Height, Overall 77.2

Overhang, Front 37.8

Ground to Top of Load Floor 34.5

Ground Clearance, Front 9.3

Ground Clearance, Rear 9.3

Cargo Box Length @ Floor 78

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 62.3

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - LARIAT 4WD SuperCab 8' Box - Starting From: $46,875

Pricing

Starting From $46,875

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3750

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2912

Curb Weight - Rear 2016

Gross Vehicle Weight Rating Cap 7050

Gross Combined Wt Rating 12400

Dead Weight Hitch - Max Trailer Wt. 7000

Dead Weight Hitch - Max Tongue Wt. 700

Wt Distributing Hitch - Max Trailer Wt. 7000

Wt Distributing Hitch - Max Tongue Wt. 700

Maximum Trailering Capacity 7000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3750

Spring Capacity - Rear 3800

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.31

Axle Ratio (:1) - Rear 3.31

Front Tire Order Code T88

Rear Tire Order Code T88

Spare Tire Order Code T24

Front Tire Size P275/55SR20

Rear Tire Size P275/55SR20

Spare Tire Size Full-Size

Front Tire Capacity 3650

Rear Tire Capacity 4056

Front Wheel Size 20 X 8.5

Rear Wheel Size 20 X 8.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 53

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 18 (Est)

EPA Fuel Economy Est - City 16 (Est)

EPA Fuel Economy Est - Hwy 22 (Est)

Engine Order Code 995

Engine Type Regular Unleaded V-8

Displacement 5.0 L/302

Fuel System Port/Direct Injection

SAE Net Horsepower @ RPM 395 @ 5750

SAE Net Torque @ RPM 400 @ 4500

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model Electronic

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 5.0

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.3

Second Leg Room 33.5

Second Shoulder Room 65.8

Second Hip Room 64.7

Wheelbase 163

Length, Overall w/o rear bumper 250.5

Width, Max w/o mirrors 79.9

Height, Overall 77

Overhang, Front 37.8

Ground to Top of Load Floor 35.7

Ground Clearance, Front 9.3

Ground Clearance, Rear 9.3

Cargo Box Length @ Floor 96

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 77.4

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - LARIAT 4WD SuperCrew 5.5' Box - Starting From: $47,985

Pricing

Starting From $47,985

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3600

Gross Axle Wt Rating - Rear 3350

Curb Weight - Front 2905

Curb Weight - Rear 1954

Gross Vehicle Weight Rating Cap 6600

Gross Combined Wt Rating 10300

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 5000

Wt Distributing Hitch - Max Tongue Wt. 500

Maximum Trailering Capacity 5000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3600

Spring Capacity - Rear 3350

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.73

Axle Ratio (:1) - Rear 3.73

Front Tire Order Code T88

Rear Tire Order Code T88

Spare Tire Order Code T24

Front Tire Size P275/65SR18

Rear Tire Size P275/65SR18

Spare Tire Size Full-Size

Front Tire Capacity 3650

Rear Tire Capacity 4056

Front Wheel Size 18 X 7.5

Rear Wheel Size 18 X 7.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 47.8

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 21 (Est)

EPA Fuel Economy Est - City 19 (Est)

EPA Fuel Economy Est - Hwy 24 (Est)

Engine Order Code 99P

Engine Type Twin Turbo Regular Unleaded V-6

Displacement 2.7 L/164

Fuel System Diesel Injection

SAE Net Horsepower @ RPM 325 @ 5000

SAE Net Torque @ RPM 400 @ 2750

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model Electronic

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.4

Second Leg Room 43.6

Second Shoulder Room 65.9

Second Hip Room 64.7

Wheelbase 145

Length, Overall w/o rear bumper 231.9

Width, Max w/o mirrors 79.9

Height, Overall 77.2

Overhang, Front 37.8

Ground to Top of Load Floor 34.6

Ground Clearance, Front 9.3

Ground Clearance, Rear 9.3

Cargo Box Length @ Floor 66

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 52.8

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - LARIAT 4WD SuperCrew 6.5' Box - Starting From: $49,235

Pricing

Starting From $49,235

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3750

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2984

Curb Weight - Rear 1929

Gross Vehicle Weight Rating Cap 7100

Gross Combined Wt Rating 12400

Dead Weight Hitch - Max Trailer Wt. 7000

Dead Weight Hitch - Max Tongue Wt. 700

Wt Distributing Hitch - Max Trailer Wt. 7000

Wt Distributing Hitch - Max Tongue Wt. 700

Maximum Trailering Capacity 7000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3750

Spring Capacity - Rear 3800

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.31

Axle Ratio (:1) - Rear 3.31

Front Tire Order Code T88

Rear Tire Order Code T88

Spare Tire Order Code T24

Front Tire Size P275/65SR18

Rear Tire Size P275/65SR18

Spare Tire Size Full-Size

Front Tire Capacity 3650

Rear Tire Capacity 4056

Front Wheel Size 18 X 7.5

Rear Wheel Size 18 X 7.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 51.1

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 18 (Est)

EPA Fuel Economy Est - City 16 (Est)

EPA Fuel Economy Est - Hwy 22 (Est)

Engine Order Code 995

Engine Type Regular Unleaded V-8

Displacement 5.0 L/302

Fuel System Diesel Injection

SAE Net Horsepower @ RPM 395 @ 5750

SAE Net Torque @ RPM 400 @ 4500

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model Electronic

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.4

Second Leg Room 43.6

Second Shoulder Room 65.9

Second Hip Room 64.7

Wheelbase 157

Length, Overall w/o rear bumper 243.7

Width, Max w/o mirrors 79.9

Height, Overall 77.3

Overhang, Front 37.8

Ground to Top of Load Floor 36.1

Ground Clearance, Front 9.3

Ground Clearance, Rear 9.3

Cargo Box Length @ Floor 78

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 62.3

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - Limited 2WD SuperCrew 5.5' Box - Starting From: $67,135

Pricing

Starting From $67,135

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3375

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2975

Curb Weight - Rear 2197

Gross Vehicle Weight Rating Cap 6750

Gross Combined Wt Rating 12600

Dead Weight Hitch - Max Trailer Wt. 7000

Dead Weight Hitch - Max Tongue Wt. 700

Wt Distributing Hitch - Max Trailer Wt. 7000

Wt Distributing Hitch - Max Tongue Wt. 700

Maximum Trailering Capacity 7000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3375

Spring Capacity - Rear 3800

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.55

Axle Ratio (:1) - Rear 3.55

Front Tire Size P275/45SR22

Rear Tire Size P275/45SR22

Spare Tire Size Full-Size

Front Tire Capacity 3650

Rear Tire Capacity 4056

Front Wheel Size 22 X 9

Rear Wheel Size 22 X 9

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 47.8

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 21 (Est)

EPA Fuel Economy Est - City 18 (Est)

EPA Fuel Economy Est - Hwy 25 (Est)

Engine Order Code 99G

Engine Type Twin Turbo Regular Unleaded V-6

Displacement 3.5 L/213

Fuel System Port/Direct Injection

SAE Net Horsepower @ RPM 450 @ 5000

SAE Net Torque @ RPM 510 @ 3500

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model None

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.5

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.4

Second Leg Room 43.6

Second Shoulder Room 65.9

Second Hip Room 64.7

Wheelbase 145

Length, Overall w/o rear bumper 231.9

Width, Max w/o mirrors 79.9

Height, Overall 75.6

Overhang, Front 37.8

Ground to Top of Load Floor 34

Ground Clearance, Front 8.7

Ground Clearance, Rear 8.7

Cargo Box Length @ Floor 66

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 52.8

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - Limited 4WD SuperCrew 5.5' Box - Starting From: $70,560

Pricing

Starting From $70,560

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3600

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 3196

Curb Weight - Rear 2228

Gross Vehicle Weight Rating Cap 6750

Gross Combined Wt Rating 14300

Dead Weight Hitch - Max Trailer Wt. 7000

Dead Weight Hitch - Max Tongue Wt. 700

Wt Distributing Hitch - Max Trailer Wt. 7000

Wt Distributing Hitch - Max Tongue Wt. 700

Maximum Trailering Capacity 7000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3600

Spring Capacity - Rear 3800

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.55

Axle Ratio (:1) - Rear 3.55

Front Tire Size P275/45SR22

Rear Tire Size P275/45SR22

Spare Tire Size Full-Size

Front Tire Capacity 3650

Rear Tire Capacity 4056

Front Wheel Size 22 X 9

Rear Wheel Size 22 X 9

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 47.8

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 19 (Est)

EPA Fuel Economy Est - City 17 (Est)

EPA Fuel Economy Est - Hwy 23 (Est)

Engine Order Code 99G

Engine Type Twin Turbo Regular Unleaded V-6

Displacement 3.5 L/213

Fuel System Port/Direct Injection

SAE Net Horsepower @ RPM 450 @ 5000

SAE Net Torque @ RPM 510 @ 3500

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model Electronic

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.5

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.4

Second Leg Room 43.6

Second Shoulder Room 65.9

Second Hip Room 64.7

Wheelbase 145

Length, Overall w/o rear bumper 231.9

Width, Max w/o mirrors 79.9

Height, Overall 77.2

Overhang, Front 37.8

Ground to Top of Load Floor 34.6

Ground Clearance, Front 9.3

Ground Clearance, Rear 9.3

Cargo Box Length @ Floor 66

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 52.8

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - Platinum 2WD SuperCrew 5.5' Box - Starting From: $54,920

Pricing

Starting From $54,920

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3375

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2692

Curb Weight - Rear 1916

Gross Vehicle Weight Rating Cap 6800

Gross Combined Wt Rating 12100

Dead Weight Hitch - Max Trailer Wt. 7000

Dead Weight Hitch - Max Tongue Wt. 700

Wt Distributing Hitch - Max Trailer Wt. 7000

Wt Distributing Hitch - Max Tongue Wt. 700

Maximum Trailering Capacity 7000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3375

Spring Capacity - Rear 3800

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.15

Axle Ratio (:1) - Rear 3.15

Front Tire Order Code T22

Rear Tire Order Code T22

Front Tire Size P275/55SR20

Rear Tire Size P275/55SR20

Spare Tire Size Full-Size

Front Tire Capacity 3650

Rear Tire Capacity 4056

Front Wheel Size 20 X 8.5

Rear Wheel Size 20 X 8.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 47.8

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 19 (Est)

EPA Fuel Economy Est - City 17 (Est)

EPA Fuel Economy Est - Hwy 25 (Est)

Engine Order Code 995

Engine Type Regular Unleaded V-8

Displacement 5.0 L/302

Fuel System Diesel Injection

SAE Net Horsepower @ RPM 395 @ 5750

SAE Net Torque @ RPM 400 @ 4500

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model None

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.4

Second Leg Room 43.6

Second Shoulder Room 65.9

Second Hip Room 64.7

Wheelbase 145

Length, Overall w/o rear bumper 231.9

Width, Max w/o mirrors 79.9

Height, Overall 75.6

Overhang, Front 37.8

Ground to Top of Load Floor 34

Ground Clearance, Front 8.7

Ground Clearance, Rear 8.7

Cargo Box Length @ Floor 66

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 52.8

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - Platinum 2WD SuperCrew 6.5' Box - Starting From: $55,220

Pricing

Starting From $55,220

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3450

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2749

Curb Weight - Rear 1892

Gross Vehicle Weight Rating Cap 6950

Gross Combined Wt Rating 12100

Dead Weight Hitch - Max Trailer Wt. 7000

Dead Weight Hitch - Max Tongue Wt. 700

Wt Distributing Hitch - Max Trailer Wt. 7000

Wt Distributing Hitch - Max Tongue Wt. 700

Maximum Trailering Capacity 7000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3450

Spring Capacity - Rear 3800

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.15

Axle Ratio (:1) - Rear 3.15

Front Tire Order Code T22

Rear Tire Order Code T22

Front Tire Size P275/55SR20

Rear Tire Size P275/55SR20

Spare Tire Size Full-Size

Front Tire Capacity 3650

Rear Tire Capacity 4056

Front Wheel Size 20 X 8.5

Rear Wheel Size 20 X 8.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 51.1

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 19 (Est)

EPA Fuel Economy Est - City 17 (Est)

EPA Fuel Economy Est - Hwy 25 (Est)

Engine Order Code 995

Engine Type Regular Unleaded V-8

Displacement 5.0 L/302

Fuel System Diesel Injection

SAE Net Horsepower @ RPM 395 @ 5750

SAE Net Torque @ RPM 400 @ 4500

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model None

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.4

Second Leg Room 43.6

Second Shoulder Room 65.9

Second Hip Room 64.7

Wheelbase 157

Length, Overall w/o rear bumper 243.7

Width, Max w/o mirrors 79.9

Height, Overall 75.7

Overhang, Front 37.8

Ground to Top of Load Floor 35.7

Ground Clearance, Front 8.4

Ground Clearance, Rear 8.4

Cargo Box Length @ Floor 78

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 62.3

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - Platinum 4WD SuperCrew 5.5' Box - Starting From: $58,345

Pricing

Starting From $58,345

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3600

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2918

Curb Weight - Rear 1950

Gross Vehicle Weight Rating Cap 7000

Gross Combined Wt Rating 12400

Dead Weight Hitch - Max Trailer Wt. 7000

Dead Weight Hitch - Max Tongue Wt. 700

Wt Distributing Hitch - Max Trailer Wt. 7000

Wt Distributing Hitch - Max Tongue Wt. 700

Maximum Trailering Capacity 7000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3600

Spring Capacity - Rear 3800

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.31

Axle Ratio (:1) - Rear 3.31

Front Tire Order Code T2P

Rear Tire Order Code T2P

Front Tire Size P275/55SR20

Rear Tire Size P275/55SR20

Spare Tire Size Full-Size

Front Tire Capacity 3650

Rear Tire Capacity 4056

Front Wheel Size 20 X 8.5

Rear Wheel Size 20 X 8.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 47.8

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 18 (Est)

EPA Fuel Economy Est - City 16 (Est)

EPA Fuel Economy Est - Hwy 22 (Est)

Engine Order Code 995

Engine Type Regular Unleaded V-8

Displacement 5.0 L/302

Fuel System Diesel Injection

SAE Net Horsepower @ RPM 395 @ 5750

SAE Net Torque @ RPM 400 @ 4500

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model Electronic

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.4

Second Leg Room 43.6

Second Shoulder Room 65.9

Second Hip Room 64.7

Wheelbase 145

Length, Overall w/o rear bumper 231.9

Width, Max w/o mirrors 79.9

Height, Overall 77.2

Overhang, Front 37.8

Ground to Top of Load Floor 34.6

Ground Clearance, Front 9.3

Ground Clearance, Rear 9.3

Cargo Box Length @ Floor 66

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 52.8

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - Platinum 4WD SuperCrew 6.5' Box - Starting From: $58,645

Pricing

Starting From $58,645

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3750

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2984

Curb Weight - Rear 1929

Gross Vehicle Weight Rating Cap 7100

Gross Combined Wt Rating 12400

Dead Weight Hitch - Max Trailer Wt. 7000

Dead Weight Hitch - Max Tongue Wt. 700

Wt Distributing Hitch - Max Trailer Wt. 7000

Wt Distributing Hitch - Max Tongue Wt. 700

Maximum Trailering Capacity 7000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3750

Spring Capacity - Rear 3800

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.31

Axle Ratio (:1) - Rear 3.31

Front Tire Order Code T2P

Rear Tire Order Code T2P

Front Tire Size P275/55SR20

Rear Tire Size P275/55SR20

Spare Tire Size Full-Size

Front Tire Capacity 3650

Rear Tire Capacity 4056

Front Wheel Size 20 X 8.5

Rear Wheel Size 20 X 8.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 51.1

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 18 (Est)

EPA Fuel Economy Est - City 16 (Est)

EPA Fuel Economy Est - Hwy 22 (Est)

Engine Order Code 995

Engine Type Regular Unleaded V-8

Displacement 5.0 L/302

Fuel System Diesel Injection

SAE Net Horsepower @ RPM 395 @ 5750

SAE Net Torque @ RPM 400 @ 4500

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model Electronic

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.4

Second Leg Room 43.6

Second Shoulder Room 65.9

Second Hip Room 64.7

Wheelbase 157

Length, Overall w/o rear bumper 243.7

Width, Max w/o mirrors 79.9

Height, Overall 77.3

Overhang, Front 37.8

Ground to Top of Load Floor 36.1

Ground Clearance, Front 9.3

Ground Clearance, Rear 9.3

Cargo Box Length @ Floor 78

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 62.3

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - Raptor 4WD SuperCab 5.5' Box - Starting From: $52,855

Pricing

Starting From $52,855

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3750

Gross Axle Wt Rating - Rear 4800

Gross Vehicle Weight Rating Cap 6650

Gross Combined Wt Rating 12050

Dead Weight Hitch - Max Trailer Wt. 6000

Dead Weight Hitch - Max Tongue Wt. 600

Wt Distributing Hitch - Max Trailer Wt. 6000

Wt Distributing Hitch - Max Tongue Wt. 600

Maximum Trailering Capacity 6000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3750

Spring Capacity - Rear 4800

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 4.10

Axle Ratio (:1) - Rear 4.10

Front Tire Size LT315/70SR17

Rear Tire Size LT315/70SR17

Spare Tire Size Full-Size

Front Tire Capacity 3750

Rear Tire Capacity 3750

Front Wheel Size 17 X 8.5

Rear Wheel Size 17 X 8.5

Spare Wheel Size Full-Size

Front Wheel Material Forged Aluminum

Rear Wheel Material Forged Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 26

Powertrain

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 16 (Est)

EPA Fuel Economy Est - City 15 (Est)

EPA Fuel Economy Est - Hwy 18 (Est)

Engine Order Code 99G

Engine Type Twin Turbo Regular Unleaded V-6

Displacement 3.5 L/213

Fuel System Port/Direct Injection

SAE Net Horsepower @ RPM 450 @ 5000

SAE Net Torque @ RPM 510 @ 3500

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model Electronic

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 800

Cold Cranking Amps @ 0° F (2nd) 800

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.5

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.3

Second Leg Room 33.5

Second Shoulder Room 65.8

Second Hip Room 64.7

Wheelbase 133

Length, Overall w/o rear bumper 220

Width, Max w/o mirrors 86.3

Height, Overall 78.5

Overhang, Front 37.8

Ground to Top of Load Floor 36.4

Ground Clearance, Front 9.9

Ground Clearance, Rear 9.9

Cargo Box Length @ Floor 66

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 52.8

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - Raptor 4WD SuperCrew 5.5' Box - Starting From: $55,840

Pricing

Starting From $55,840

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3750

Gross Axle Wt Rating - Rear 4800

Gross Vehicle Weight Rating Cap 7050

Gross Combined Wt Rating 14250

Dead Weight Hitch - Max Trailer Wt. 8000

Dead Weight Hitch - Max Tongue Wt. 800

Wt Distributing Hitch - Max Trailer Wt. 8000

Wt Distributing Hitch - Max Tongue Wt. 800

Maximum Trailering Capacity 8000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3750

Spring Capacity - Rear 4800

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 4.10

Axle Ratio (:1) - Rear 4.10

Front Tire Size LT315/70SR17

Rear Tire Size LT315/70SR17

Spare Tire Size Full-Size

Front Tire Capacity 3750

Rear Tire Capacity 3750

Front Wheel Size 17 X 8.5

Rear Wheel Size 17 X 8.5

Spare Wheel Size Full-Size

Front Wheel Material Forged Aluminum

Rear Wheel Material Forged Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 16 (Est)

EPA Fuel Economy Est - City 15 (Est)

EPA Fuel Economy Est - Hwy 18 (Est)

Engine Order Code 99G

Engine Type Twin Turbo Regular Unleaded V-6

Displacement 3.5 L/213

Fuel System Port/Direct Injection

SAE Net Horsepower @ RPM 450 @ 5000

SAE Net Torque @ RPM 510 @ 3500

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model Electronic

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 800

Cold Cranking Amps @ 0° F (2nd) 800

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.5

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.4

Second Leg Room 43.6

Second Shoulder Room 65.9

Second Hip Room 64.7

Wheelbase 145

Length, Overall w/o rear bumper 231.9

Width, Max w/o mirrors 86.3

Height, Overall 78.5

Overhang, Front 37.8

Ground to Top of Load Floor 36.3

Ground Clearance, Front 9.8

Ground Clearance, Rear 9.8

Cargo Box Length @ Floor 66

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 52.8

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - XL 2WD Reg Cab 6.5' Box - Starting From: $28,155

Pricing

Starting From $28,155

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3000

Gross Axle Wt Rating - Rear 3350

Curb Weight - Front 2383

Curb Weight - Rear 1686

Gross Vehicle Weight Rating Cap 6100

Gross Combined Wt Rating 9500

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 5000

Wt Distributing Hitch - Max Tongue Wt. 500

Maximum Trailering Capacity 5000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3000

Spring Capacity - Rear 3350

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.55

Axle Ratio (:1) - Rear 3.55

Front Tire Order Code T7C

Rear Tire Order Code T7C

Front Tire Size P245/70SR17

Rear Tire Size P245/70SR17

Spare Tire Size Full-Size

Front Tire Capacity 3650

Rear Tire Capacity 4050

Front Wheel Size 17 X 7.5

Rear Wheel Size 17 X 7.5

Spare Wheel Size Full-Size

Front Wheel Material Steel

Rear Wheel Material Steel

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 40.7

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 23

Powertrain

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 22 (Est)

EPA Fuel Economy Est - City 20 (Est)

EPA Fuel Economy Est - Hwy 25 (Est)

Engine Order Code 99B

Engine Type Regular Unleaded V-6

Displacement 3.3 L

Fuel System Port/Direct Injection

SAE Net Horsepower @ RPM 290 @ 6500

SAE Net Torque @ RPM 265 @ 4000

Trans Order Code 446

Trans Type 6

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.17

Second Gear Ratio (:1) 2.34

Third Gear Ratio (:1) 1.52

Fourth Gear Ratio (:1) 1.14

Fifth Gear Ratio (:1) 0.86

Sixth Gear Ratio (:1) 0.69

Reverse Ratio (:1) 3.40

Trans PTO Access No

Transfer Case Model None

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler None

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 2.7

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 3

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Wheelbase 122

Length, Overall w/o rear bumper 209.3

Width, Max w/o mirrors 79.9

Height, Overall 75.5

Overhang, Front 37.8

Ground to Top of Load Floor 34.7

Ground Clearance, Front 8.8

Ground Clearance, Rear 8.8

Cargo Box Length @ Floor 78

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 62.3

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - XL 2WD Reg Cab 8' Box - Starting From: $28,455

Pricing

Starting From $28,455

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3000

Gross Axle Wt Rating - Rear 3350

Curb Weight - Front 2477

Curb Weight - Rear 1687

Gross Vehicle Weight Rating Cap 6170

Gross Combined Wt Rating 9600

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 5000

Wt Distributing Hitch - Max Tongue Wt. 500

Maximum Trailering Capacity 5000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3000

Spring Capacity - Rear 3350

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.15

Axle Ratio (:1) - Rear 3.15

Front Tire Order Code T8C

Rear Tire Order Code T8C

Front Tire Size LT275/65SR18

Rear Tire Size LT275/65SR18

Spare Tire Size Full-Size

Front Tire Capacity 3982

Rear Tire Capacity 4550

Front Wheel Size 18 X 7.5

Rear Wheel Size 18 X 7.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 46.1

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 21 (Est)

EPA Fuel Economy Est - City 18 (Est)

EPA Fuel Economy Est - Hwy 25 (Est)

Engine Order Code 994

Engine Type Twin Turbo Regular Unleaded V-6

Displacement 3.5 L/213

Fuel System Port/Direct Injection

SAE Net Horsepower @ RPM 375 @ 5000

SAE Net Torque @ RPM 470 @ 3500

Trans Order Code 446

Trans Type 6

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.17

Second Gear Ratio (:1) 2.34

Third Gear Ratio (:1) 1.52

Fourth Gear Ratio (:1) 1.14

Fifth Gear Ratio (:1) 0.86

Sixth Gear Ratio (:1) 0.69

Reverse Ratio (:1) 3.40

Trans PTO Access No

Transfer Case Model None

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 2.7

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 3

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Wheelbase 141

Length, Overall w/o rear bumper 227.9

Width, Max w/o mirrors 79.9

Height, Overall 75.1

Overhang, Front 37.8

Ground to Top of Load Floor 36.9

Ground Clearance, Front 8.5

Ground Clearance, Rear 8.5

Cargo Box Length @ Floor 96

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 77.4

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - XL 2WD SuperCab 6.5' Box - Starting From: $32,240

Pricing

Starting From $32,240

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3225

Gross Axle Wt Rating - Rear 3350

Curb Weight - Front 2560

Curb Weight - Rear 1855

Gross Vehicle Weight Rating Cap 6300

Gross Combined Wt Rating 9900

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 5000

Wt Distributing Hitch - Max Tongue Wt. 500

Maximum Trailering Capacity 5000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3225

Spring Capacity - Rear 3350

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.31

Axle Ratio (:1) - Rear 3.31

Front Tire Order Code T22

Rear Tire Order Code T22

Spare Tire Order Code T22

Front Tire Size P275/55SR20

Rear Tire Size P275/55SR20

Spare Tire Size Full-Size

Front Tire Capacity 3650

Rear Tire Capacity 4056

Front Wheel Size 20 X 8.5

Rear Wheel Size 20 X 8.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 47.1

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 21 (Est)

EPA Fuel Economy Est - City 18 (Est)

EPA Fuel Economy Est - Hwy 25 (Est)

Engine Order Code 991

Engine Type Intercooled Turbo Diesel V-6

Displacement 3.0 L

Fuel System Diesel Injection

SAE Net Horsepower @ RPM 250 @ 3250

SAE Net Torque @ RPM 440 @ 1750

Trans Order Code 446

Trans Type 6

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.17

Second Gear Ratio (:1) 2.34

Third Gear Ratio (:1) 1.52

Fourth Gear Ratio (:1) 1.14

Fifth Gear Ratio (:1) 0.86

Sixth Gear Ratio (:1) 0.69

Reverse Ratio (:1) 3.40

Trans PTO Access No

Transfer Case Model None

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 240

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 6

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.3

Second Leg Room 33.5

Second Shoulder Room 65.8

Second Hip Room 64.7

Wheelbase 145

Length, Overall w/o rear bumper 231.9

Width, Max w/o mirrors 79.9

Height, Overall 75.5

Overhang, Front 37.8

Ground to Top of Load Floor 34.1

Ground Clearance, Front 8.7

Ground Clearance, Rear 8.7

Cargo Box Length @ Floor 78

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 62.3

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - XL 2WD SuperCab 8' Box - Starting From: $33,545

Pricing

Starting From $33,545

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3525

Gross Axle Wt Rating - Rear 3350

Curb Weight - Front 2743

Curb Weight - Rear 1901

Gross Vehicle Weight Rating Cap 7000

Gross Combined Wt Rating 10100

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 5000

Wt Distributing Hitch - Max Tongue Wt. 500

Maximum Trailering Capacity 5000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3525

Spring Capacity - Rear 3350

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.73

Axle Ratio (:1) - Rear 3.73

Front Tire Order Code T8C

Rear Tire Order Code T8C

Front Tire Size LT275/65SR18

Rear Tire Size LT275/65SR18

Spare Tire Size Full-Size

Front Tire Capacity 3982

Rear Tire Capacity 4550

Front Wheel Size 18 X 7.5

Rear Wheel Size 18 X 7.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 53

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 21 (Est)

EPA Fuel Economy Est - City 18 (Est)

EPA Fuel Economy Est - Hwy 26 (Est)

Engine Order Code 99P

Engine Type Twin Turbo Regular Unleaded V-6

Displacement 2.7 L/164

Fuel System Port/Direct Injection

SAE Net Horsepower @ RPM 325 @ 5000

SAE Net Torque @ RPM 400 @ 2750

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model None

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 240

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 2.7

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.3

Second Leg Room 33.5

Second Shoulder Room 65.8

Second Hip Room 64.7

Wheelbase 163

Length, Overall w/o rear bumper 250.5

Width, Max w/o mirrors 79.9

Height, Overall 75.5

Overhang, Front 37.8

Ground to Top of Load Floor 35.9

Ground Clearance, Front 8.6

Ground Clearance, Rear 8.6

Cargo Box Length @ Floor 96

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 77.4

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - XL 2WD SuperCrew 5.5' Box - Starting From: $34,695

Pricing

Starting From $34,695

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3300

Gross Axle Wt Rating - Rear 3350

Curb Weight - Front 2604

Curb Weight - Rear 1924

Gross Vehicle Weight Rating Cap 6280

Gross Combined Wt Rating 10000

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 5000

Wt Distributing Hitch - Max Tongue Wt. 500

Maximum Trailering Capacity 5000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3300

Spring Capacity - Rear 3350

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.31

Axle Ratio (:1) - Rear 3.31

Front Tire Order Code T22

Rear Tire Order Code T22

Spare Tire Order Code T22

Front Tire Size P275/55SR20

Rear Tire Size P275/55SR20

Spare Tire Size Full-Size

Front Tire Capacity 3650

Rear Tire Capacity 4056

Front Wheel Size 20 X 8.5

Rear Wheel Size 20 X 8.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 47.8

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 26

Powertrain

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 21 (Est)

EPA Fuel Economy Est - City 18 (Est)

EPA Fuel Economy Est - Hwy 25 (Est)

Engine Order Code 991

Engine Type Intercooled Turbo Diesel V-6

Displacement 3.0 L

Fuel System Diesel Injection

SAE Net Horsepower @ RPM 250 @ 3250

SAE Net Torque @ RPM 440 @ 1750

Trans Order Code 446

Trans Type 6

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.17

Second Gear Ratio (:1) 2.34

Third Gear Ratio (:1) 1.52

Fourth Gear Ratio (:1) 1.14

Fifth Gear Ratio (:1) 0.86

Sixth Gear Ratio (:1) 0.69

Reverse Ratio (:1) 3.40

Trans PTO Access No

Transfer Case Model None

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 240

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 6

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.4

Second Leg Room 43.6

Second Shoulder Room 65.9

Second Hip Room 64.7

Wheelbase 145

Length, Overall w/o rear bumper 231.9

Width, Max w/o mirrors 79.9

Height, Overall 75.6

Overhang, Front 37.8

Ground to Top of Load Floor 34

Ground Clearance, Front 8.7

Ground Clearance, Rear 8.7

Cargo Box Length @ Floor 66

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 52.8

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - XL 2WD SuperCrew 6.5' Box - Starting From: $36,000

Pricing

Starting From $36,000

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3450

Gross Axle Wt Rating - Rear 3350

Curb Weight - Front 2746

Curb Weight - Rear 1882

Gross Vehicle Weight Rating Cap 6500

Gross Combined Wt Rating 10100

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 5000

Wt Distributing Hitch - Max Tongue Wt. 500

Maximum Trailering Capacity 5000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3450

Spring Capacity - Rear 3350

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.73

Axle Ratio (:1) - Rear 3.73

Front Tire Order Code T22

Rear Tire Order Code T22

Spare Tire Order Code T22

Front Tire Size P275/55SR20

Rear Tire Size P275/55SR20

Spare Tire Size Full-Size

Front Tire Capacity 3982

Rear Tire Capacity 4056

Front Wheel Size 20 X 8.5

Rear Wheel Size 20 X 8.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 51.1

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 21 (Est)

EPA Fuel Economy Est - City 18 (Est)

EPA Fuel Economy Est - Hwy 26 (Est)

Engine Order Code 99P

Engine Type Twin Turbo Regular Unleaded V-6

Displacement 2.7 L/164

Fuel System Diesel Injection

SAE Net Horsepower @ RPM 325 @ 5000

SAE Net Torque @ RPM 400 @ 2750

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model None

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 240

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 6

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.4

Second Leg Room 43.6

Second Shoulder Room 65.9

Second Hip Room 64.7

Wheelbase 157

Length, Overall w/o rear bumper 243.7

Width, Max w/o mirrors 79.9

Height, Overall 75.7

Overhang, Front 37.8

Ground to Top of Load Floor 35.7

Ground Clearance, Front 8.4

Ground Clearance, Rear 8.4

Cargo Box Length @ Floor 78

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 62.3

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - XL 4WD Reg Cab 6.5' Box - Starting From: $32,800

Pricing

Starting From $32,800

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3000

Gross Axle Wt Rating - Rear 3350

Curb Weight - Front 2585

Curb Weight - Rear 1758

Gross Vehicle Weight Rating Cap 6120

Gross Combined Wt Rating 9800

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 5000

Wt Distributing Hitch - Max Tongue Wt. 500

Maximum Trailering Capacity 5000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3000

Spring Capacity - Rear 3350

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.31

Axle Ratio (:1) - Rear 3.31

Front Tire Order Code T7C

Rear Tire Order Code T7C

Front Tire Size P265/70SR17

Rear Tire Size P265/70SR17

Spare Tire Size Full-Size

Front Tire Capacity 3650

Rear Tire Capacity 4050

Front Wheel Size 17 X 7.5

Rear Wheel Size 17 X 7.5

Spare Wheel Size Full-Size

Front Wheel Material Steel

Rear Wheel Material Steel

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 40.7

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 23

Powertrain

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 20 (Est)

EPA Fuel Economy Est - City 18 (Est)

EPA Fuel Economy Est - Hwy 23 (Est)

Engine Order Code 99B

Engine Type Regular Unleaded V-6

Displacement 3.3 L

Fuel System Port/Direct Injection

SAE Net Horsepower @ RPM 290 @ 6500

SAE Net Torque @ RPM 265 @ 4000

Trans Order Code 446

Trans Type 6

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.17

Second Gear Ratio (:1) 2.34

Third Gear Ratio (:1) 1.52

Fourth Gear Ratio (:1) 1.14

Fifth Gear Ratio (:1) 0.86

Sixth Gear Ratio (:1) 0.69

Reverse Ratio (:1) 3.40

Trans PTO Access No

Transfer Case Model Electronic

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 2.7

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 3

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Wheelbase 122

Length, Overall w/o rear bumper 209.3

Width, Max w/o mirrors 79.9

Height, Overall 76.9

Overhang, Front 37.8

Ground to Top of Load Floor 34.8

Ground Clearance, Front 9.4

Ground Clearance, Rear 9.4

Cargo Box Length @ Floor 78

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 62.3

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - XL 4WD Reg Cab 8' Box - Starting From: $33,100

Pricing

Starting From $33,100

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3225

Gross Axle Wt Rating - Rear 3350

Curb Weight - Front 2718

Curb Weight - Rear 1700

Gross Vehicle Weight Rating Cap 6390

Gross Combined Wt Rating 9900

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 5000

Wt Distributing Hitch - Max Tongue Wt. 500

Maximum Trailering Capacity 5000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3225

Spring Capacity - Rear 3350

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.73

Axle Ratio (:1) - Rear 3.73

Front Tire Order Code T8C

Rear Tire Order Code T8C

Front Tire Size P265/70SR17

Rear Tire Size P265/70SR17

Spare Tire Size Full-Size

Front Tire Capacity 3982

Rear Tire Capacity 4550

Front Wheel Size 18 X 7.5

Rear Wheel Size 18 X 7.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 46.1

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 19 (Est)

EPA Fuel Economy Est - City 17 (Est)

EPA Fuel Economy Est - Hwy 23 (Est)

Engine Order Code 994

Engine Type Twin Turbo Regular Unleaded V-6

Displacement 3.5 L/213

Fuel System Port/Direct Injection

SAE Net Horsepower @ RPM 375 @ 5000

SAE Net Torque @ RPM 470 @ 3500

Trans Order Code 446

Trans Type 6

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.17

Second Gear Ratio (:1) 2.34

Third Gear Ratio (:1) 1.52

Fourth Gear Ratio (:1) 1.14

Fifth Gear Ratio (:1) 0.86

Sixth Gear Ratio (:1) 0.69

Reverse Ratio (:1) 3.40

Trans PTO Access No

Transfer Case Model Electronic

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 2.7

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 3

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Wheelbase 141

Length, Overall w/o rear bumper 227.9

Width, Max w/o mirrors 79.9

Height, Overall 76.9

Overhang, Front 37.8

Ground to Top of Load Floor 36.5

Ground Clearance, Front 9.4

Ground Clearance, Rear 9.4

Cargo Box Length @ Floor 96

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 77.4

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - XL 4WD SuperCab 6.5' Box - Starting From: $35,670

Pricing

Starting From $35,670

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3450

Gross Axle Wt Rating - Rear 3350

Curb Weight - Front 2801

Curb Weight - Rear 1874

Gross Vehicle Weight Rating Cap 7000

Gross Combined Wt Rating 10100

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 5000

Wt Distributing Hitch - Max Tongue Wt. 500

Maximum Trailering Capacity 5000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3450

Spring Capacity - Rear 3350

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.73

Axle Ratio (:1) - Rear 3.73

Front Tire Order Code T2P

Rear Tire Order Code T2P

Spare Tire Order Code T2P

Front Tire Size P275/55SR20

Rear Tire Size P275/55SR20

Spare Tire Size Full-Size

Front Tire Capacity 3650

Rear Tire Capacity 4056

Front Wheel Size 20 X 8.5

Rear Wheel Size 20 X 8.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 47.1

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 19 (Est)

EPA Fuel Economy Est - City 17 (Est)

EPA Fuel Economy Est - Hwy 23 (Est)

Engine Order Code 991

Engine Type Intercooled Turbo Diesel V-6

Displacement 3.0 L

Fuel System Diesel Injection

SAE Net Horsepower @ RPM 250 @ 3250

SAE Net Torque @ RPM 440 @ 1750

Trans Order Code 446

Trans Type 6

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.17

Second Gear Ratio (:1) 2.34

Third Gear Ratio (:1) 1.52

Fourth Gear Ratio (:1) 1.14

Fifth Gear Ratio (:1) 0.86

Sixth Gear Ratio (:1) 0.69

Reverse Ratio (:1) 3.40

Trans PTO Access No

Transfer Case Model Electronic

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 240

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 2.7

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 6

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.3

Second Leg Room 33.5

Second Shoulder Room 65.8

Second Hip Room 64.7

Wheelbase 145

Length, Overall w/o rear bumper 231.9

Width, Max w/o mirrors 79.9

Height, Overall 77.2

Overhang, Front 37.8

Ground to Top of Load Floor 34.5

Ground Clearance, Front 9.3

Ground Clearance, Rear 9.3

Cargo Box Length @ Floor 78

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 62.3

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - XL 4WD SuperCab 8' Box - Starting From: $37,925

Pricing

Starting From $37,925

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3750

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2912

Curb Weight - Rear 2016

Gross Vehicle Weight Rating Cap 7050

Gross Combined Wt Rating 12400

Dead Weight Hitch - Max Trailer Wt. 7000

Dead Weight Hitch - Max Tongue Wt. 700

Wt Distributing Hitch - Max Trailer Wt. 7000

Wt Distributing Hitch - Max Tongue Wt. 700

Maximum Trailering Capacity 7000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3750

Spring Capacity - Rear 3800

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.31

Axle Ratio (:1) - Rear 3.31

Front Tire Order Code T8C

Rear Tire Order Code T8C

Front Tire Size P265/70SR17

Rear Tire Size P265/70SR17

Spare Tire Size Full-Size

Front Tire Capacity 3982

Rear Tire Capacity 4550

Front Wheel Size 18 X 7.5

Rear Wheel Size 18 X 7.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 53

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 18 (Est)

EPA Fuel Economy Est - City 16 (Est)

EPA Fuel Economy Est - Hwy 22 (Est)

Engine Order Code 995

Engine Type Regular Unleaded V-8

Displacement 5.0 L/302

Fuel System Port/Direct Injection

SAE Net Horsepower @ RPM 395 @ 5750

SAE Net Torque @ RPM 400 @ 4500

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model Electronic

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 240

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 5.0

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 8

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.3

Second Leg Room 33.5

Second Shoulder Room 65.8

Second Hip Room 64.7

Wheelbase 163

Length, Overall w/o rear bumper 250.5

Width, Max w/o mirrors 79.9

Height, Overall 77

Overhang, Front 37.8

Ground to Top of Load Floor 35.7

Ground Clearance, Front 9.3

Ground Clearance, Rear 9.3

Cargo Box Length @ Floor 96

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 77.4

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - XL 4WD SuperCrew 5.5' Box - Starting From: $38,205

Pricing

Starting From $38,205

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3525

Gross Axle Wt Rating - Rear 3350

Curb Weight - Front 2826

Curb Weight - Rear 1944

Gross Vehicle Weight Rating Cap 6600

Gross Combined Wt Rating 10200

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 5000

Wt Distributing Hitch - Max Tongue Wt. 500

Maximum Trailering Capacity 5000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3525

Spring Capacity - Rear 3350

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.73

Axle Ratio (:1) - Rear 3.73

Front Tire Order Code T2P

Rear Tire Order Code T2P

Spare Tire Order Code T2P

Front Tire Size P275/55SR20

Rear Tire Size P275/55SR20

Spare Tire Size Full-Size

Front Tire Capacity 3650

Rear Tire Capacity 4056

Front Wheel Size 20 X 8.5

Rear Wheel Size 20 X 8.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 47.8

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 19 (Est)

EPA Fuel Economy Est - City 17 (Est)

EPA Fuel Economy Est - Hwy 23 (Est)

Engine Order Code 991

Engine Type Intercooled Turbo Diesel V-6

Displacement 3.0 L

Fuel System Diesel Injection

SAE Net Horsepower @ RPM 250 @ 3250

SAE Net Torque @ RPM 440 @ 1750

Trans Order Code 446

Trans Type 6

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.17

Second Gear Ratio (:1) 2.34

Third Gear Ratio (:1) 1.52

Fourth Gear Ratio (:1) 1.14

Fifth Gear Ratio (:1) 0.86

Sixth Gear Ratio (:1) 0.69

Reverse Ratio (:1) 3.40

Trans PTO Access No

Transfer Case Model Electronic

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 240

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 6

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.4

Second Leg Room 43.6

Second Shoulder Room 65.9

Second Hip Room 64.7

Wheelbase 145

Length, Overall w/o rear bumper 231.9

Width, Max w/o mirrors 79.9

Height, Overall 77.2

Overhang, Front 37.8

Ground to Top of Load Floor 34.6

Ground Clearance, Front 9.3

Ground Clearance, Rear 9.3

Cargo Box Length @ Floor 66

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 52.8

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - XL 4WD SuperCrew 6.5' Box - Starting From: $40,460

Pricing

Starting From $40,460

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3750

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2984

Curb Weight - Rear 1929

Gross Vehicle Weight Rating Cap 7050

Gross Combined Wt Rating 12400

Dead Weight Hitch - Max Trailer Wt. 7000

Dead Weight Hitch - Max Tongue Wt. 700

Wt Distributing Hitch - Max Trailer Wt. 7000

Wt Distributing Hitch - Max Tongue Wt. 700

Maximum Trailering Capacity 7000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3750

Spring Capacity - Rear 3800

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.31

Axle Ratio (:1) - Rear 3.31

Front Tire Order Code T2P

Rear Tire Order Code T2P

Spare Tire Order Code T2P

Front Tire Size P275/55SR20

Rear Tire Size P275/55SR20

Spare Tire Size Full-Size

Front Tire Capacity 3982

Rear Tire Capacity 4056

Front Wheel Size 20 X 8.5

Rear Wheel Size 20 X 8.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 51.1

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 18 (Est)

EPA Fuel Economy Est - City 16 (Est)

EPA Fuel Economy Est - Hwy 22 (Est)

Engine Order Code 995

Engine Type Regular Unleaded V-8

Displacement 5.0 L/302

Fuel System Diesel Injection

SAE Net Horsepower @ RPM 395 @ 5750

SAE Net Torque @ RPM 400 @ 4500

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model Electronic

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 240

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 6

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.4

Second Leg Room 43.6

Second Shoulder Room 65.9

Second Hip Room 64.7

Wheelbase 157

Length, Overall w/o rear bumper 243.7

Width, Max w/o mirrors 79.9

Height, Overall 77.3

Overhang, Front 37.8

Ground to Top of Load Floor 36.1

Ground Clearance, Front 9.3

Ground Clearance, Rear 9.3

Cargo Box Length @ Floor 78

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 62.3

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - XLT 2WD Reg Cab 6.5' Box - Starting From: $34,160

Pricing

Starting From $34,160

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3000

Gross Axle Wt Rating - Rear 3350

Curb Weight - Front 2383

Curb Weight - Rear 1686

Gross Vehicle Weight Rating Cap 6100

Gross Combined Wt Rating 9500

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 5000

Wt Distributing Hitch - Max Tongue Wt. 500

Maximum Trailering Capacity 5000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3000

Spring Capacity - Rear 3350

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.55

Axle Ratio (:1) - Rear 3.55

Front Tire Order Code T7C

Rear Tire Order Code T7C

Front Tire Size P245/70SR17

Rear Tire Size P245/70SR17

Spare Tire Size Full-Size

Front Tire Capacity 3650

Rear Tire Capacity 4056

Front Wheel Size 17 X 7.5

Rear Wheel Size 17 X 7.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 40.7

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 23

Powertrain

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 22 (Est)

EPA Fuel Economy Est - City 20 (Est)

EPA Fuel Economy Est - Hwy 25 (Est)

Engine Order Code 99B

Engine Type Regular Unleaded V-6

Displacement 3.3 L

Fuel System Port/Direct Injection

SAE Net Horsepower @ RPM 290 @ 6500

SAE Net Torque @ RPM 265 @ 4000

Trans Order Code 446

Trans Type 6

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.17

Second Gear Ratio (:1) 2.34

Third Gear Ratio (:1) 1.52

Fourth Gear Ratio (:1) 1.14

Fifth Gear Ratio (:1) 0.86

Sixth Gear Ratio (:1) 0.69

Reverse Ratio (:1) 3.40

Trans PTO Access No

Transfer Case Model None

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.3

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 3

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Wheelbase 122

Length, Overall w/o rear bumper 209.3

Width, Max w/o mirrors 79.9

Height, Overall 75.5

Overhang, Front 37.8

Ground to Top of Load Floor 34.7

Ground Clearance, Front 8.8

Ground Clearance, Rear 8.8

Cargo Box Length @ Floor 78

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 62.3

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - XLT 2WD Reg Cab 8' Box - Starting From: $34,460

Pricing

Starting From $34,460

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3000

Gross Axle Wt Rating - Rear 3350

Curb Weight - Front 2477

Curb Weight - Rear 1687

Gross Vehicle Weight Rating Cap 6170

Gross Combined Wt Rating 9600

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 5000

Wt Distributing Hitch - Max Tongue Wt. 500

Maximum Trailering Capacity 5000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3000

Spring Capacity - Rear 3350

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.15

Axle Ratio (:1) - Rear 3.15

Front Tire Order Code T8C

Rear Tire Order Code T8C

Front Tire Size LT275/65SR18

Rear Tire Size LT275/65SR18

Spare Tire Size Full-Size

Front Tire Capacity 3982

Rear Tire Capacity 4550

Front Wheel Size 18 X 7.5

Rear Wheel Size 18 X 7.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 46.1

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 21 (Est)

EPA Fuel Economy Est - City 18 (Est)

EPA Fuel Economy Est - Hwy 25 (Est)

Engine Order Code 994

Engine Type Twin Turbo Regular Unleaded V-6

Displacement 3.5 L/213

Fuel System Port/Direct Injection

SAE Net Horsepower @ RPM 375 @ 5000

SAE Net Torque @ RPM 470 @ 3500

Trans Order Code 446

Trans Type 6

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.17

Second Gear Ratio (:1) 2.34

Third Gear Ratio (:1) 1.52

Fourth Gear Ratio (:1) 1.14

Fifth Gear Ratio (:1) 0.86

Sixth Gear Ratio (:1) 0.69

Reverse Ratio (:1) 3.40

Trans PTO Access No

Transfer Case Model None

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.3

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 3

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Wheelbase 141

Length, Overall w/o rear bumper 227.9

Width, Max w/o mirrors 79.9

Height, Overall 75.1

Overhang, Front 37.8

Ground to Top of Load Floor 36.9

Ground Clearance, Front 8.5

Ground Clearance, Rear 8.5

Cargo Box Length @ Floor 96

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 77.4

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - XLT 2WD SuperCab 6.5' Box - Starting From: $37,070

Pricing

Starting From $37,070

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3225

Gross Axle Wt Rating - Rear 3350

Curb Weight - Front 2560

Curb Weight - Rear 1855

Gross Vehicle Weight Rating Cap 6300

Gross Combined Wt Rating 9900

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 5000

Wt Distributing Hitch - Max Tongue Wt. 500

Maximum Trailering Capacity 5000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3225

Spring Capacity - Rear 3350

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.31

Axle Ratio (:1) - Rear 3.31

Front Tire Order Code T82

Rear Tire Order Code T82

Spare Tire Order Code T22

Front Tire Size P265/60SR18

Rear Tire Size P265/60SR18

Spare Tire Size Full-Size

Front Tire Capacity 3982

Rear Tire Capacity 4550

Front Wheel Size 20 X 8.5

Rear Wheel Size 20 X 8.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 47.1

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 21 (Est)

EPA Fuel Economy Est - City 18 (Est)

EPA Fuel Economy Est - Hwy 25 (Est)

Engine Order Code 991

Engine Type Intercooled Turbo Diesel V-6

Displacement 3.0 L

Fuel System Diesel Injection

SAE Net Horsepower @ RPM 250 @ 3250

SAE Net Torque @ RPM 440 @ 1750

Trans Order Code 446

Trans Type 6

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.17

Second Gear Ratio (:1) 2.34

Third Gear Ratio (:1) 1.52

Fourth Gear Ratio (:1) 1.14

Fifth Gear Ratio (:1) 0.86

Sixth Gear Ratio (:1) 0.69

Reverse Ratio (:1) 3.40

Trans PTO Access No

Transfer Case Model None

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.3

Second Leg Room 33.5

Second Shoulder Room 65.8

Second Hip Room 64.7

Wheelbase 145

Length, Overall w/o rear bumper 231.9

Width, Max w/o mirrors 79.9

Height, Overall 75.5

Overhang, Front 37.8

Ground to Top of Load Floor 34.1

Ground Clearance, Front 8.7

Ground Clearance, Rear 8.7

Cargo Box Length @ Floor 78

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 62.3

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - XLT 2WD SuperCab 8' Box - Starting From: $38,375

Pricing

Starting From $38,375

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3525

Gross Axle Wt Rating - Rear 3350

Curb Weight - Front 2743

Curb Weight - Rear 1901

Gross Vehicle Weight Rating Cap 7000

Gross Combined Wt Rating 10100

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 5000

Wt Distributing Hitch - Max Tongue Wt. 500

Maximum Trailering Capacity 5000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3525

Spring Capacity - Rear 3350

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.73

Axle Ratio (:1) - Rear 3.73

Front Tire Order Code T82

Rear Tire Order Code T82

Spare Tire Order Code T22

Front Tire Size P265/60SR18

Rear Tire Size P265/60SR18

Spare Tire Size Full-Size

Front Tire Capacity 3982

Rear Tire Capacity 4550

Front Wheel Size 20 X 8.5

Rear Wheel Size 20 X 8.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 53

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 21 (Est)

EPA Fuel Economy Est - City 18 (Est)

EPA Fuel Economy Est - Hwy 26 (Est)

Engine Order Code 99P

Engine Type Twin Turbo Regular Unleaded V-6

Displacement 2.7 L/164

Fuel System Port/Direct Injection

SAE Net Horsepower @ RPM 325 @ 5000

SAE Net Torque @ RPM 400 @ 2750

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model None

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 2.7

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.3

Second Leg Room 33.5

Second Shoulder Room 65.8

Second Hip Room 64.7

Wheelbase 163

Length, Overall w/o rear bumper 250.5

Width, Max w/o mirrors 79.9

Height, Overall 75.5

Overhang, Front 37.8

Ground to Top of Load Floor 35.9

Ground Clearance, Front 8.6

Ground Clearance, Rear 8.6

Cargo Box Length @ Floor 96

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 77.4

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - XLT 2WD SuperCrew 5.5' Box - Starting From: $39,420

Pricing

Starting From $39,420

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3300

Gross Axle Wt Rating - Rear 3350

Curb Weight - Front 2604

Curb Weight - Rear 1924

Gross Vehicle Weight Rating Cap 6280

Gross Combined Wt Rating 10000

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 5000

Wt Distributing Hitch - Max Tongue Wt. 500

Maximum Trailering Capacity 5000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3300

Spring Capacity - Rear 3350

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.31

Axle Ratio (:1) - Rear 3.31

Front Tire Order Code T82

Rear Tire Order Code T82

Spare Tire Order Code T22

Front Tire Size P265/60SR18

Rear Tire Size P265/60SR18

Spare Tire Size Full-Size

Front Tire Capacity 3982

Rear Tire Capacity 4550

Front Wheel Size 20 X 8.5

Rear Wheel Size 20 X 8.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 47.8

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 21 (Est)

EPA Fuel Economy Est - City 18 (Est)

EPA Fuel Economy Est - Hwy 25 (Est)

Engine Order Code 991

Engine Type Intercooled Turbo Diesel V-6

Displacement 3.0 L

Fuel System Diesel Injection

SAE Net Horsepower @ RPM 250 @ 3250

SAE Net Torque @ RPM 440 @ 1750

Trans Order Code 446

Trans Type 6

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.17

Second Gear Ratio (:1) 2.34

Third Gear Ratio (:1) 1.52

Fourth Gear Ratio (:1) 1.14

Fifth Gear Ratio (:1) 0.86

Sixth Gear Ratio (:1) 0.69

Reverse Ratio (:1) 3.40

Trans PTO Access No

Transfer Case Model None

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.4

Second Leg Room 43.6

Second Shoulder Room 65.9

Second Hip Room 64.7

Wheelbase 145

Length, Overall w/o rear bumper 231.9

Width, Max w/o mirrors 79.9

Height, Overall 75.6

Overhang, Front 37.8

Ground to Top of Load Floor 34

Ground Clearance, Front 8.7

Ground Clearance, Rear 8.7

Cargo Box Length @ Floor 66

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 52.8

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - XLT 2WD SuperCrew 6.5' Box - Starting From: $40,725

Pricing

Starting From $40,725

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3450

Gross Axle Wt Rating - Rear 3350

Curb Weight - Front 2746

Curb Weight - Rear 1882

Gross Vehicle Weight Rating Cap 6500

Gross Combined Wt Rating 10100

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 5000

Wt Distributing Hitch - Max Tongue Wt. 500

Maximum Trailering Capacity 5000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3450

Spring Capacity - Rear 3350

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.73

Axle Ratio (:1) - Rear 3.73

Front Tire Order Code T82

Rear Tire Order Code T82

Spare Tire Order Code T22

Front Tire Size P265/60SR18

Rear Tire Size P265/60SR18

Spare Tire Size Full-Size

Front Tire Capacity 3982

Rear Tire Capacity 4550

Front Wheel Size 18 X 7.5

Rear Wheel Size 18 X 7.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 51.1

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 26

Powertrain

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 21 (Est)

EPA Fuel Economy Est - City 18 (Est)

EPA Fuel Economy Est - Hwy 26 (Est)

Engine Order Code 99P

Engine Type Twin Turbo Regular Unleaded V-6

Displacement 2.7 L/164

Fuel System Diesel Injection

SAE Net Horsepower @ RPM 325 @ 5000

SAE Net Torque @ RPM 400 @ 2750

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model None

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.4

Second Leg Room 43.6

Second Shoulder Room 65.9

Second Hip Room 64.7

Wheelbase 157

Length, Overall w/o rear bumper 243.7

Width, Max w/o mirrors 79.9

Height, Overall 75.7

Overhang, Front 37.8

Ground to Top of Load Floor 35.7

Ground Clearance, Front 8.4

Ground Clearance, Rear 8.4

Cargo Box Length @ Floor 78

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 62.3

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - XLT 4WD Reg Cab 6.5' Box - Starting From: $37,585

Pricing

Starting From $37,585

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3000

Gross Axle Wt Rating - Rear 3350

Curb Weight - Front 2585

Curb Weight - Rear 1758

Gross Vehicle Weight Rating Cap 6120

Gross Combined Wt Rating 9800

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 5000

Wt Distributing Hitch - Max Tongue Wt. 500

Maximum Trailering Capacity 5000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3000

Spring Capacity - Rear 3350

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.31

Axle Ratio (:1) - Rear 3.31

Front Tire Order Code T7C

Rear Tire Order Code T7C

Front Tire Size P265/70SR17

Rear Tire Size P265/70SR17

Spare Tire Size Full-Size

Front Tire Capacity 3650

Rear Tire Capacity 4056

Front Wheel Size 17 X 7.5

Rear Wheel Size 17 X 7.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 40.7

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 23

Powertrain

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 20 (Est)

EPA Fuel Economy Est - City 18 (Est)

EPA Fuel Economy Est - Hwy 23 (Est)

Engine Order Code 99B

Engine Type Regular Unleaded V-6

Displacement 3.3 L

Fuel System Port/Direct Injection

SAE Net Horsepower @ RPM 290 @ 6500

SAE Net Torque @ RPM 265 @ 4000

Trans Order Code 446

Trans Type 6

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.17

Second Gear Ratio (:1) 2.34

Third Gear Ratio (:1) 1.52

Fourth Gear Ratio (:1) 1.14

Fifth Gear Ratio (:1) 0.86

Sixth Gear Ratio (:1) 0.69

Reverse Ratio (:1) 3.40

Trans PTO Access No

Transfer Case Model Electronic

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 2.7

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 3

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Wheelbase 122

Length, Overall w/o rear bumper 209.3

Width, Max w/o mirrors 79.9

Height, Overall 76.9

Overhang, Front 37.8

Ground to Top of Load Floor 34.8

Ground Clearance, Front 9.4

Ground Clearance, Rear 9.4

Cargo Box Length @ Floor 78

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 62.3

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - XLT 4WD Reg Cab 8' Box - Starting From: $37,885

Pricing

Starting From $37,885

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3225

Gross Axle Wt Rating - Rear 3350

Curb Weight - Front 2718

Curb Weight - Rear 1700

Gross Vehicle Weight Rating Cap 6390

Gross Combined Wt Rating 9900

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 5000

Wt Distributing Hitch - Max Tongue Wt. 500

Maximum Trailering Capacity 5000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3225

Spring Capacity - Rear 3350

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.73

Axle Ratio (:1) - Rear 3.73

Front Tire Order Code T8C

Rear Tire Order Code T8C

Front Tire Size P265/70SR17

Rear Tire Size P265/70SR17

Spare Tire Size Full-Size

Front Tire Capacity 3982

Rear Tire Capacity 4550

Front Wheel Size 18 X 7.5

Rear Wheel Size 18 X 7.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 46.1

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 19 (Est)

EPA Fuel Economy Est - City 17 (Est)

EPA Fuel Economy Est - Hwy 23 (Est)

Engine Order Code 994

Engine Type Twin Turbo Regular Unleaded V-6

Displacement 3.5 L/213

Fuel System Port/Direct Injection

SAE Net Horsepower @ RPM 375 @ 5000

SAE Net Torque @ RPM 470 @ 3500

Trans Order Code 446

Trans Type 6

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.17

Second Gear Ratio (:1) 2.34

Third Gear Ratio (:1) 1.52

Fourth Gear Ratio (:1) 1.14

Fifth Gear Ratio (:1) 0.86

Sixth Gear Ratio (:1) 0.69

Reverse Ratio (:1) 3.40

Trans PTO Access No

Transfer Case Model Electronic

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 2.7

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 3

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Wheelbase 141

Length, Overall w/o rear bumper 227.9

Width, Max w/o mirrors 79.9

Height, Overall 76.9

Overhang, Front 37.8

Ground to Top of Load Floor 36.5

Ground Clearance, Front 9.4

Ground Clearance, Rear 9.4

Cargo Box Length @ Floor 96

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 77.4

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - XLT 4WD SuperCab 6.5' Box - Starting From: $40,495

Pricing

Starting From $40,495

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3450

Gross Axle Wt Rating - Rear 3350

Curb Weight - Front 2801

Curb Weight - Rear 1874

Gross Vehicle Weight Rating Cap 7000

Gross Combined Wt Rating 10100

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 5000

Wt Distributing Hitch - Max Tongue Wt. 500

Maximum Trailering Capacity 5000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3450

Spring Capacity - Rear 3350

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.73

Axle Ratio (:1) - Rear 3.73

Front Tire Order Code T84

Rear Tire Order Code T84

Spare Tire Order Code T24

Front Tire Size P275/55SR20

Rear Tire Size P275/55SR20

Spare Tire Size Full-Size

Front Tire Capacity 3982

Rear Tire Capacity 4550

Front Wheel Size 20 X 8.5

Rear Wheel Size 20 X 8.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 47.1

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 19 (Est)

EPA Fuel Economy Est - City 17 (Est)

EPA Fuel Economy Est - Hwy 23 (Est)

Engine Order Code 991

Engine Type Intercooled Turbo Diesel V-6

Displacement 3.0 L

Fuel System Diesel Injection

SAE Net Horsepower @ RPM 250 @ 3250

SAE Net Torque @ RPM 440 @ 1750

Trans Order Code 446

Trans Type 6

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.17

Second Gear Ratio (:1) 2.34

Third Gear Ratio (:1) 1.52

Fourth Gear Ratio (:1) 1.14

Fifth Gear Ratio (:1) 0.86

Sixth Gear Ratio (:1) 0.69

Reverse Ratio (:1) 3.40

Trans PTO Access No

Transfer Case Model Electronic

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.3

Second Leg Room 33.5

Second Shoulder Room 65.8

Second Hip Room 64.7

Wheelbase 145

Length, Overall w/o rear bumper 231.9

Width, Max w/o mirrors 79.9

Height, Overall 77.2

Overhang, Front 37.8

Ground to Top of Load Floor 34.5

Ground Clearance, Front 9.3

Ground Clearance, Rear 9.3

Cargo Box Length @ Floor 78

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 62.3

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - XLT 4WD SuperCab 8' Box - Starting From: $42,750

Pricing

Starting From $42,750

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3750

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2912

Curb Weight - Rear 2016

Gross Vehicle Weight Rating Cap 7050

Gross Combined Wt Rating 12400

Dead Weight Hitch - Max Trailer Wt. 7000

Dead Weight Hitch - Max Tongue Wt. 700

Wt Distributing Hitch - Max Trailer Wt. 7000

Wt Distributing Hitch - Max Tongue Wt. 700

Maximum Trailering Capacity 7000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3750

Spring Capacity - Rear 3800

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.31

Axle Ratio (:1) - Rear 3.31

Front Tire Order Code T84

Rear Tire Order Code T84

Spare Tire Order Code T24

Front Tire Size P275/55SR20

Rear Tire Size P275/55SR20

Spare Tire Size Full-Size

Front Tire Capacity 3982

Rear Tire Capacity 4550

Front Wheel Size 20 X 8.5

Rear Wheel Size 20 X 8.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 53

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 18 (Est)

EPA Fuel Economy Est - City 16 (Est)

EPA Fuel Economy Est - Hwy 22 (Est)

Engine Order Code 995

Engine Type Regular Unleaded V-8

Displacement 5.0 L/302

Fuel System Port/Direct Injection

SAE Net Horsepower @ RPM 395 @ 5750

SAE Net Torque @ RPM 400 @ 4500

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model Electronic

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 5.0

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 8

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.3

Second Leg Room 33.5

Second Shoulder Room 65.8

Second Hip Room 64.7

Wheelbase 163

Length, Overall w/o rear bumper 250.5

Width, Max w/o mirrors 79.9

Height, Overall 77

Overhang, Front 37.8

Ground to Top of Load Floor 35.7

Ground Clearance, Front 9.3

Ground Clearance, Rear 9.3

Cargo Box Length @ Floor 96

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 77.4

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - XLT 4WD SuperCrew 5.5' Box - Starting From: $42,915

Pricing

Starting From $42,915

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3525

Gross Axle Wt Rating - Rear 3350

Curb Weight - Front 2826

Curb Weight - Rear 1944

Gross Vehicle Weight Rating Cap 6600

Gross Combined Wt Rating 10200

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 5000

Wt Distributing Hitch - Max Tongue Wt. 500

Maximum Trailering Capacity 5000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3525

Spring Capacity - Rear 3350

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.73

Axle Ratio (:1) - Rear 3.73

Front Tire Order Code T84

Rear Tire Order Code T84

Spare Tire Order Code T24

Front Tire Size P275/55SR20

Rear Tire Size P275/55SR20

Spare Tire Size Full-Size

Front Tire Capacity 3982

Rear Tire Capacity 4550

Front Wheel Size 20 X 8.5

Rear Wheel Size 20 X 8.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 47.8

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 19 (Est)

EPA Fuel Economy Est - City 17 (Est)

EPA Fuel Economy Est - Hwy 23 (Est)

Engine Order Code 991

Engine Type Intercooled Turbo Diesel V-6

Displacement 3.0 L

Fuel System Diesel Injection

SAE Net Horsepower @ RPM 250 @ 3250

SAE Net Torque @ RPM 440 @ 1750

Trans Order Code 446

Trans Type 6

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.17

Second Gear Ratio (:1) 2.34

Third Gear Ratio (:1) 1.52

Fourth Gear Ratio (:1) 1.14

Fifth Gear Ratio (:1) 0.86

Sixth Gear Ratio (:1) 0.69

Reverse Ratio (:1) 3.40

Trans PTO Access No

Transfer Case Model Electronic

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.4

Second Leg Room 43.6

Second Shoulder Room 65.9

Second Hip Room 64.7

Wheelbase 145

Length, Overall w/o rear bumper 231.9

Width, Max w/o mirrors 79.9

Height, Overall 77.2

Overhang, Front 37.8

Ground to Top of Load Floor 34.6

Ground Clearance, Front 9.3

Ground Clearance, Rear 9.3

Cargo Box Length @ Floor 66

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 52.8

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Ford F-150 - XLT 4WD SuperCrew 6.5' Box - Starting From: $45,170

Pricing

Starting From $45,170

Destination Charge $1,595

Chassis

Gross Axle Wt Rating - Front 3750

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2984

Curb Weight - Rear 1929

Gross Vehicle Weight Rating Cap 7050

Gross Combined Wt Rating 12400

Dead Weight Hitch - Max Trailer Wt. 7000

Dead Weight Hitch - Max Tongue Wt. 700

Wt Distributing Hitch - Max Trailer Wt. 7000

Wt Distributing Hitch - Max Tongue Wt. 700

Maximum Trailering Capacity 7000

Suspension Type - Front Double Wishbone

Suspension Type - Rear Leaf

Spring Capacity - Front 3750

Spring Capacity - Rear 3800

Axle Type - Front Independent

Axle Type - Rear Rigid Axle

Axle Capacity - Front 3750

Axle Capacity - Rear 4800

Axle Ratio (:1) - Front 3.31

Axle Ratio (:1) - Rear 3.31

Front Tire Order Code T84

Rear Tire Order Code T84

Spare Tire Order Code T24

Front Tire Size P275/55SR20

Rear Tire Size P275/55SR20

Spare Tire Size Full-Size

Front Tire Capacity 3982

Rear Tire Capacity 4550

Front Wheel Size 18 X 7.5

Rear Wheel Size 18 X 7.5

Spare Wheel Size Full-Size

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Rack-Pinion

Turning Diameter - Curb to Curb 51.1

Brake Type 4-Wheel Disc

Brake ABS System 4-Wheel

Brake ABS System (Second Line) 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13.8

Rear Brake Rotor Diam x Thickness 13.7

Fuel Tank Capacity, Approx 36

Powertrain

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 18 (Est)

EPA Fuel Economy Est - City 16 (Est)

EPA Fuel Economy Est - Hwy 22 (Est)

Engine Order Code 995

Engine Type Regular Unleaded V-8

Displacement 5.0 L/302

Fuel System Diesel Injection

SAE Net Horsepower @ RPM 395 @ 5750

SAE Net Torque @ RPM 400 @ 4500

Trans Order Code 44G

Trans Type 10

Trans Description Cont. Automatic w/OD

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.98

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.27

Reverse Ratio (:1) 4.87

Trans PTO Access No

Transfer Case Model Electronic

Transfer Case Power Take Off No

Cold Cranking Amps @ 0° F (Primary) 610

Cold Cranking Amps @ 0° F (2nd) 610

Maximum Alternator Capacity (amps) 200

Engine Oil Cooler Regular Duty

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type iron

Engine Cylinder Count 6

Engine Valve Count 4

Dimensions

Passenger Capacity 5

Front Head Room 40.8

Front Leg Room 43.9

Front Shoulder Room 66.7

Front Hip Room 62.5

Second Head Room 40.4

Second Leg Room 43.6

Second Shoulder Room 65.9

Second Hip Room 64.7

Wheelbase 157

Length, Overall w/o rear bumper 243.7

Width, Max w/o mirrors 79.9

Height, Overall 77.3

Overhang, Front 37.8

Ground to Top of Load Floor 36.1

Ground Clearance, Front 9.3

Ground Clearance, Rear 9.3

Cargo Box Length @ Floor 78

Cargo Box Width @ Top, Rear 65.2

Cargo Box Width @ Floor 65.2

Cargo Box Width @ Wheelhousings 50.6

Cargo Box (Area) Height 21.4

Tailgate Width 60.3

Cargo Volume 62.3

Warranty

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Corrosion Years 5

Corrosion Miles/km Unlimited

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Shop Ford F-150

Mon:	9:00AM - 7:00PM
Tue:	9:00AM - 7:00PM
Wed:	9:00AM - 7:00PM
Thu:	9:00AM - 7:00PM
Fri:	9:00AM - 7:00PM
Sat:	9:00AM - 6:00PM
Sun:	Closed

Mon:	7:00AM - 7:00PM
Tue:	7:00AM - 7:00PM
Wed:	7:00AM - 7:00PM
Thu:	7:00AM - 7:00PM
Fri:	7:00AM - 6:00PM
Sat:	8:00AM - 5:00PM
Sun:	Closed

Mon:	7:00AM - 7:00PM
Tue:	7:00AM - 7:00PM
Wed:	7:00AM - 7:00PM
Thu:	7:00AM - 7:00PM
Fri:	7:00AM - 6:00PM
Sat:	8:00AM - 5:00PM
Sun:	Closed

New 2024 Ford F-150

New Ford F-150 Lease & Finance Specials For April 2024

2024 F-150 XLT 3.5L V6 Ecoboost. XLT High Package, XLT Black Appearance Package, 18" Gloss Black Wheels, Tow/Haul Package, FX4 Package, Extended Range Fuel Tank, Bed Utility Package...Plus Much More!!

Standing Tall and Making Sure the Job Is Done Right Is Just Part of the Process for a Ford F-150 of Your Own

An Unequaled Track Record of Excellence

An Astonishingly Sleek and Captivating Pickup

Stay Hooked up with Futuristic LCD Screen Technology

Selecting the Right F-150 Trim Package for You

Ford F-150 XL

Ford F-150 Raptor

Ford F-150 Platinum

Ford F-150 Highlights

Taking Power to Another Level

Space for the Whole Gang (and Your Equipment, Too)

The F-150 Owns Towing

Never Easing up on Safety

Trim Level Market Research

Shop Ford F-150

Register with Social

Register with Email

New 2024 Ford F-150

New Ford F-150 Lease & Finance Specials For April 2024

2024 F-150 XLT 3.5L V6 Ecoboost. XLT High Package, XLT Black Appearance Package, 18" Gloss Black Wheels, Tow/Haul Package, FX4 Package, Extended Range Fuel Tank, Bed Utility Package...Plus Much More!!

Standing Tall and Making Sure the Job Is Done Right Is Just Part of the Process for a Ford F-150 of Your Own

An Unequaled Track Record of Excellence

An Astonishingly Sleek and Captivating Pickup

Stay Hooked up with Futuristic LCD Screen Technology

Selecting the Right F-150 Trim Package for You

Ford F-150 XL

Ford F-150 Raptor

Ford F-150 Platinum

Ford F-150 Highlights

Taking Power to Another Level

Space for the Whole Gang (and Your Equipment, Too)

The F-150 Owns Towing

Never Easing up on Safety

Trim Level Market Research

Shop Ford F-150

Log In with Social

Log In with Email

Reset Password

Register with Social

Register with Email
